Volkswagen Caravelle T4 1996 Long
2.4 D (78 Hp) Syncro
Generation Caravelle T4 1996 Long
Body Type Van
Seats 6
2003
End Year
135 km/h
Maximum Speed
4
Doors
Volkswagen Caravelle T4 1996 Long Key Specs
Body Type
Van
Doors
4-5
Drive Wheel
All wheel drive (4x4)
End Of Production
2003
Engine Aspiration
Naturally aspirated engine
Engine Oil Capacity
5.5 l
Fuel Type
Diesel
Fuel Tank Capacity
80 l
Generation
Caravelle (T4, 1996) Long
Kerb Weight
1900 kg
Maximum Speed
135 km/h
Modification (Engine)
2.4 D (78 Hp) Syncro
Number Of Cylinders
5
Power
78 Hp @ 3700 rpm.
Power Steering
Hydraulic Steering
Powertrain Architecture
Internal Combustion engine
Seats
6-9
Start Of Production
1996
Volkswagen Caravelle T4 1996 Long Technical Specifications
General
Body type
Van
Brand
Volkswagen
Doors
4-5
End of production
2003
Generation
Caravelle (T4, 1996) Long
Model
Caravelle
Modification (Engine)
2.4 D (78 Hp) Syncro
Powertrain Architecture
Internal Combustion engine
Seats
6-9
Start of production
1996
Performance
CO2 emissions (NEDC)
292 g/km
Fuel Type
Diesel
Fuel consumption (economy) - combined (NEDC)
10.8 l/100 km
Fuel consumption (economy) - extra urban (NEDC)
8.6 l/100 km
Fuel consumption (economy) - urban (NEDC)
14.7 l/100 km
Maximum speed
135 km/h
Dimensions
Front overhang
968 mm
Front track
1589 mm
Height
1940 mm
Length
5189 mm
Minimum turning circle (turning diameter)
12.9 m
Rear (Back) track
1554 mm
Rear overhang
901 mm
Ride height (ground clearance)
180 mm
Wading depth
350 mm
Wheelbase
3320 mm
Width
1840 mm
Engine
Compression ratio
22.5
Coolant
9 l
Cylinder Bore
79.5 mm
Engine Model/Code
AAB
Engine aspiration
Naturally aspirated engine
Engine configuration
Inline
Engine displacement
2370 cm
Engine layout
Front, Transverse
Engine oil capacity
5.5 l
Engine oil specification
Log in to see.
Fuel injection system
Diesel - Standard diesel injection (SDI)
Number of cylinders
5
Number of valves per cylinder
2
Power
78 Hp @ 3700 rpm.
Torque
164 Nm @ 1800-2200 rpm.
Drivetrain
Drive wheel
All wheel drive (4x4)
Front brakes
Disc
Front suspension
Independent torsion bar, double wishbone, Transverse stabilizer
Number of gears and type of gearbox
5 gears, manual transmission
Power steering
Hydraulic Steering
Rear brakes
Disc
Rear suspension
Independent coil spring, Trailing arm
Steering type
Steering rack and pinion
Tires size
205/65 R15
Wheel rims size
6J x 15
Space
Fuel tank capacity
80 l
Kerb Weight
1900 kg
Max load
800-900 kg
Max. roof load
100 kg
Max. weight
2700-2800 kg
Permitted towbar download
100 kg
