Volkswagen Caravelle T3 1984 1.7 D (57 Hp) 5MT Full Specifications
logo
Volkswagen Caravelle T3 1984 1.7 D (57 Hp) 5MT

Volkswagen Caravelle T3 1984
1.7 D (57 Hp) 5MT

Generation Caravelle T3
Body Type Van
Seats 7
1989 End Year
115 km/h Maximum Speed
4 Doors

Volkswagen Caravelle T3 1984 Key Specs

Body Type
Van
Doors
4-5
Drive Wheel
Rear wheel drive
End Of Production
1989
Engine Aspiration
Naturally aspirated engine
Engine Oil Capacity
4.5 l
Fuel Type
Diesel
Fuel Consumption (economy) - Extra Urban
8 l/100 km
Fuel Tank Capacity
60 l
Generation
Caravelle (T3)
Kerb Weight
1550-1580 kg
Maximum Speed
115 km/h
Modification (Engine)
1.7 D (57 Hp) 5MT
Number Of Cylinders
4
Power
57 Hp @ 4500 rpm.
Powertrain Architecture
Internal Combustion engine
Seats
7-9
Start Of Production
1984

Volkswagen Caravelle T3 1984 Technical Specifications

General

Body type
Van
Brand
Volkswagen
Doors
4-5
End of production
1989
Generation
Caravelle (T3)
Model
Caravelle
Modification (Engine)
1.7 D (57 Hp) 5MT
Powertrain Architecture
Internal Combustion engine
Seats
7-9
Start of production
1984

Performance

Fuel Type
Diesel
Fuel consumption (economy) - extra urban
8 l/100 km
Fuel consumption (economy) - urban
9.8 l/100 km
Maximum speed
115 km/h

Dimensions

Climb angle
15°
Front overhang
1175 mm
Front track
1583 mm
Height
1950 mm
Length
4600 mm
Minimum turning circle (turning diameter)
10.7 m
Rear (Back) track
1570 mm
Rear overhang
965 mm
Ride height (ground clearance)
190 mm
Wheelbase
2460 mm
Width
1845 mm

Engine

Compression ratio
23
Coolant
16 l
Cylinder Bore
79.5 mm
Engine Model/Code
KY
Engine aspiration
Naturally aspirated engine
Engine configuration
Inline
Engine displacement
1715 cm
Engine layout
Rear, Longitudinal
Engine oil capacity
4.5 l
Engine oil specification
Log in to see.
Fuel injection system
Diesel - Standard diesel injection (SDI)
Number of cylinders
4
Number of valves per cylinder
2
Power
57 Hp @ 4500 rpm.
Torque
103 Nm @ 2800 rpm.

Drivetrain

Drive wheel
Rear wheel drive
Front brakes
Disc
Front suspension
Coil spring, Double wishbone, Transverse stabilizer
Number of gears and type of gearbox
5 gears, manual transmission
Rear brakes
Drum
Rear suspension
Independent coil spring, Trailing arm
Steering type
Steering rack and pinion
Tires size
185/80 R14; 205/70 R14
Wheel rims size
5.5J x 14; 6J x 14

Space

Fuel tank capacity
60 l
Kerb Weight
1550-1580 kg
Max load
810-1020 kg
Max. roof load
100 kg
Max. weight
2360-2600 kg
Permitted towbar download
50 kg
