Volkswagen Transporter T5 2009 Panel Van
2.0 TDI (180 Hp) 4MOTION L1H1
Generation Transporter T5 2009 Panel Van
Body Type Van
Seats 2
2015
End Year
188 km/h
Maximum Speed
4
Doors
Volkswagen Transporter T5 2009 Panel Van Key Specs
Acceleration 0 - 100 Km/h
10.4 sec
Acceleration 0 - 62 Mph
10.4 sec
Body Type
Van
Doors
4-5
Drive Wheel
All wheel drive (4x4)
End Of Production
2015
Engine Aspiration
BiTurbo, Intercooler
Engine Oil Capacity
7 l
Engine Systems
Particulate filter
Fuel Type
Diesel
Fuel Tank Capacity
80 l
Generation
Transporter (T5, 2009) Panel Van
Kerb Weight
1890-2279 kg
Maximum Speed
188 km/h
Modification (Engine)
2.0 TDI (180 Hp) 4MOTION L1H1
Number Of Cylinders
4
Power
180 Hp @ 4000 rpm.
Power Steering
Hydraulic Steering
Powertrain Architecture
Internal Combustion engine
Seats
2-3
Start Of Production
2009
Volkswagen Transporter T5 2009 Panel Van Gallery
Volkswagen Transporter T5 2009 Panel Van Technical Specifications
General
Body type
Van
Brand
Volkswagen
Doors
4-5
End of production
2015
Generation
Transporter (T5, 2009) Panel Van
Model
Transporter
Modification (Engine)
2.0 TDI (180 Hp) 4MOTION L1H1
Powertrain Architecture
Internal Combustion engine
Seats
2-3
Start of production
2009
Performance
Acceleration 0 - 100 km/h
10.4 sec
Acceleration 0 - 60 mph
9.9 sec
Acceleration 0 - 62 mph
10.4 sec
CO2 emissions (NEDC)
214-221 g/km
Emission standard
Euro 5
Fuel Type
Diesel
Fuel consumption (economy) - combined (NEDC)
8.1-8.4 l/100 km
Fuel consumption (economy) - extra urban (NEDC)
6.9-7.2 l/100 km
Fuel consumption (economy) - urban (NEDC)
10.2-10.5 l/100 km
Maximum speed
188 km/h
Dimensions
Approach angle
21°
Climb angle
37°
Departure angle
17°
Front overhang
896 mm
Height
1990 mm
Length
4892 mm
Minimum turning circle (turning diameter)
11.9 m
Ramp-over (brakeover) angle
14°
Rear overhang
996 mm
Ride height (ground clearance)
201 mm
Wading depth
300 mm
Wheelbase
3000 mm
Width
1904 mm
Engine
Compression ratio
16.5
Coolant
11 l
Cylinder Bore
81 mm
Engine Model/Code
EA189 / CFCA
Engine aspiration
BiTurbo, Intercooler
Engine configuration
Inline
Engine displacement
1968 cm
Engine layout
Front, Transverse
Engine oil capacity
7 l
Engine oil specification
Log in to see.
Engine systems
Particulate filter
Fuel injection system
Diesel Commonrail
Number of cylinders
4
Number of valves per cylinder
4
Power
180 Hp @ 4000 rpm.
Torque
400 Nm @ 1500-2000 rpm.
Drivetrain
Drive wheel
All wheel drive (4x4)
Front brakes
Ventilated discs, 340x32.5 mm
Front suspension
Independent, type McPherson with coil spring and anti-roll bar
Number of gears and type of gearbox
6 gears, manual transmission
Power steering
Hydraulic Steering
Rear brakes
Ventilated discs, 294x22 mm
Rear suspension
Independent coil spring, Transverse stabilizer, Trailing arm
Steering type
Steering rack and pinion
Tires size
215/60 R17; 235/55 R17; 255/45 R18
Wheel rims size
7J x 17; 8J x 18
Space
Fuel tank capacity
80 l
Kerb Weight
1890-2279 kg
Max load
910-921 kg
Max. roof load
100 kg
Max. weight
2800-3200 kg
Permitted towbar download
100 kg
