Volkswagen Caddy Maxi Cargo 5 2024
1.5 TSI (150 Hp) eHybrid DSG
Hybrid Car
Body Type Minivan
Battery Capacity 25.7 KW
114-118 km
Electric Range
181 km/h
Maximum Speed
4
Doors
Volkswagen Caddy Maxi Cargo 5 2024 Key Specs
All-electric Range (WLTP)
114-118 km
Average Energy Consumption (WLTP)
18.8-19.3 kWh/100 km
Body Type
Minivan
Doors
4-5
Drive Wheel
Front wheel drive
Engine Aspiration
Turbocharger, Intercooler
Engine Systems
Start & Stop SystemParticulate filter
Fuel Type
Petrol / electricity
Generation
Caddy Maxi Cargo V
Gross Battery Capacity
25.7 kWh
Kerb Weight
1725-1738 kg
Maximum Speed
181 km/h
Modification (Engine)
1.5 TSI (150 Hp) eHybrid DSG
Number Of Cylinders
4
Power
116 Hp @ 3500 rpm.
Power Steering
Electric Steering
Powertrain Architecture
PHEV (Plug-in Hybrid Electric Vehicle)
Seats
2
Start Of Production
August, 2024
System Power
150 Hp
System Torque
350 Nm
Wheel Rims Size
6.5J x 17
Volkswagen Caddy Maxi Cargo 5 2024 Gallery
Volkswagen Caddy Maxi Cargo 5 2024 Technical Specifications
General
Body type
Minivan
Brand
Volkswagen
Doors
4-5
Generation
Caddy Maxi Cargo V
Model
Caddy
Modification (Engine)
1.5 TSI (150 Hp) eHybrid DSG
Powertrain Architecture
PHEV (Plug-in Hybrid Electric Vehicle)
Seats
2
Start of production
August, 2024
Performance
CO2 emissions (WLTP)
11-12 g/km
Combined fuel consumption (WLTP)
0.5 l/100 km
Emission standard
Euro 6e
Fuel Type
Petrol / electricity
Maximum speed
181 km/h
Electric
All-electric range (WLTP)
114-118 km
Average Energy consumption (WLTP)
18.8-19.3 kWh/100 km
Charging ports number 0
Log in to see.
Electric motor location number 1
Between the combustion engine and the transmission
Electric motor type number 1
Synchronous
Gross battery capacity
25.7 kWh
Net (usable) battery capacity
19.7 kWh
System power
150 Hp
System torque
350 Nm
Internal Engine
Cylinder Bore
74.5 mm
Engine Model/Code
EA211 evo2
Engine aspiration
Turbocharger, Intercooler
Engine configuration
Inline
Engine displacement
1498 cm
Engine layout
Front, Transverse
Engine systems
Start & Stop SystemParticulate filter
Fuel injection system
Direct injection
Number of cylinders
4
Number of valves per cylinder
4
Piston Stroke
85.9 mm
Power
116 Hp @ 3500 rpm.
Power per litre
77.4 Hp/l
Torque
250 Nm @ 1500-3000 rpm.
Valvetrain
DOHC
Dimensions
Approach angle
16.6°
Departure angle
16.1°
Front overhang
890 mm
Height
1860 mm
Length
4853 mm
Minimum turning circle (turning diameter)
12.1 m
Ramp-over (brakeover) angle
13°
Rear overhang
993 mm
Ride height (ground clearance)
159 mm
Wheelbase
2970 mm
Width
1855 mm
Drivetrain
Drive wheel
Front wheel drive
Front brakes
Ventilated discs
Front suspension
Independent, type McPherson with coil spring and anti-roll bar
Number of gears and type of gearbox
6 gears, automatic transmission DSG
Power steering
Electric Steering
Rear brakes
Disc
Rear suspension
Rigid axle suspension, Trailing arm, Coil spring
Steering type
Steering rack and pinion
Tires size
215/55 R17
Wheel rims size
6.5J x 17
Space
Kerb Weight
1725-1738 kg
Max load
762-775 kg
Max. weight
2500 kg
Permitted towbar download
75 kg
