Renault Trafic 2 Phase 2006 2.0 (120 Hp) L2H1

Renault Trafic 2 Phase 2006 2.0 (120 Hp) L2H1
Brand : Renault
Model : Trafic
Generation : Trafic 2 Phase 2
Body Type : Minivan
Fuel Type : Petrol (Gasoline)
Number Of Gears : 6
Seats : 9
Doors : 4
Start Year : 2006

Technical Sheet

Acceleration 0 - 100 Km/h
: 14.5 sec
Acceleration 0 - 62 Mph
: 14.5 sec
Body Type
: Minivan
Doors
: 4
End Of Production
: 2011
Fuel System
: Multi-point indirect injection
Fuel Type
: Petrol (Gasoline)
Fuel Consumption (economy) - Combined
: 10.3 l/100 km
Generation
: Trafic II (Phase II)
Maximum Speed
: 160 km/h
Modification (Engine)
: 2.0 (120 Hp) L2H1
Number Of Gears (manual Transmission)
: 6
Power
: 120 Hp @ 4700 rpm.
Powertrain Architecture
: Internal Combustion engine
Seats
: 9
Start Of Production
: 2006
General
Body type Minivan
Brand Renault
Doors 4
End of production 2011
Generation Trafic II (Phase II)
Model Trafic
Modification (Engine) 2.0 (120 Hp) L2H1
Powertrain Architecture Internal Combustion engine
Seats 9
Start of production 2006
Performance
Acceleration 0 - 100 km/h 14.5 sec
Acceleration 0 - 60 mph 13.8 sec
Acceleration 0 - 62 mph 14.5 sec
Fuel Type Petrol (Gasoline)
Fuel consumption (economy) - combined 10.3 l/100 km
Fuel consumption (economy) - extra urban 8.6 l/100 km
Fuel consumption (economy) - urban 13.3 l/100 km
Maximum speed 160 km/h
Dimensions
Front track 1615 mm
Height 1951 mm
Length 5182 mm
Rear (Back) track 1630 mm
Wheelbase 3498 mm
Width 1904 mm
Engine
Coolant 6.5 l
Engine aspiration Naturally aspirated engine
Engine displacement 1998 cm
Engine oil capacity 5.25 l
Fuel System Multi-point indirect injection
Model Engine F4R
Number of valves per cylinder 4
Position of cylinders Inline
Power 120 Hp @ 4700 rpm.
Torque 190 Nm @ 3750 rpm.
Drivetrain
Drive wheel Front wheel drive
Front brakes Ventilated discs
Number of Gears (manual transmission) 6
Rear brakes Disc
Steering type Steering rack and pinion
Tires size 205/65 R16
Wheel rims size R16
Space
Fuel tank capacity 90 l
Kerb Weight 1851 kg
Max load 1014 kg
Max. weight 2865 kg
