Seat Leon 5 Sportstourer 2020 1.4 e-HYBRID (204 Hp) DSG

Seat Leon 5 Sportstourer 2020 1.4 e-HYBRID (204 Hp) DSG
Brand : Seat
Model : Leon
Generation : Leon 5 Sportstourer
Engine Type : Hybrid
Battery Capacity : 12.8 KW
Electric Range : 58
Start Year : 2020

Photos for cars

Technical Sheet Seat Leon 5 Sportstourer 2020

Acceleration 0 - 100 Km/h
: 7.7 sec
Acceleration 0 - 62 Mph
: 7.7 sec
All-electric Range (WLTP)
: 58-63 km
Average Energy Consumption (WLTP)
: 18.1 kWh/100 km
Battery Capacity
: 12.8 kWh
Body Type
: Station wagon (estate)
Doors
: 5
Fuel System
: Direct injection
Fuel Type
: petrol / electricity
Generation
: Leon IV Sportstourer
Maximum Speed
: 220 km/h
Modification (Engine)
: 1.4 e-HYBRID (204 Hp) DSG
Number Of Gears (automatic Transmission)
: 6 DSG
Number Of Cylinders
: 4
Power
: 150 Hp @ 5000-6000 rpm.
Powertrain Architecture
: PHEV (Plug-in Hybrid Electric Vehicle)
Seats
: 5
Start Of Production
: 2020
System Power
: 204 Hp

General Seat Leon 5 Sportstourer 2020

General
Body type Station wagon (estate)
Brand Seat
Doors 5
Generation Leon IV Sportstourer
Model Leon
Modification (Engine) 1.4 e-HYBRID (204 Hp) DSG
Powertrain Architecture PHEV (Plug-in Hybrid Electric Vehicle)
Seats 5
Start of production 2020

Performance Seat Leon 5 Sportstourer 2020

Performance
Acceleration 0 - 100 km/h 7.7 sec
Acceleration 0 - 60 mph 7.3 sec
Acceleration 0 - 62 mph 7.7 sec
CO2 emissions (WLTP) 27-30 g/km
Combined fuel consumption (WLTP) 1.2-1.3 l/100 km
Emission standard Euro 6d-ISC-FCM
Fuel Type petrol / electricity
Maximum speed 220 km/h

Electric Seat Leon 5 Sportstourer 2020

Electric
Battery capacity 12.8 kWh
All-electric range (WLTP) 58-63 km
Average Energy consumption (WLTP) 18.1 kWh/100 km
Electric motor power number 1 116 Hp
Electric motor Torque number 1 330 Nm
System power 204 Hp
System torque 350 Nm

Internal Engine Seat Leon 5 Sportstourer 2020

Internal Engine
Compression ratio 10
Cylinder Bore 74.5 mm
Engine aspiration Turbocharger
Engine displacement 1395 cm
Engine location Front, Transverse
Engine oil capacity 4.5 l
Engine systems Start & Stop SystemParticulate filter
Fuel System Direct injection
Model Engine DGE
Number of cylinders 4
Number of valves per cylinder 4
Piston Stroke 80 mm
Position of cylinders Inline
Power 150 Hp @ 5000-6000 rpm.
Power per litre 107.5 Hp/l
Torque 250 Nm @ 1550-3500 rpm.
Valvetrain DOHC

Dimensions Seat Leon 5 Sportstourer 2020

Dimensions
Front overhang 888 mm
Front track 1545 mm
Height 1448 mm
Length 4642 mm
Minimum turning circle (turning diameter) 10.5 m
Rear (Back) track 1516 mm
Rear overhang 1068 mm
Wheelbase 2686 mm
Width 1799 mm

Drivetrain Seat Leon 5 Sportstourer 2020

Drivetrain
Drive wheel Front wheel drive
Front brakes Ventilated discs, 312x25 mm
Front suspension Coil spring, Independent type McPherson
Number of Gears (automatic transmission) 6 DSG
Power steering Electric Steering
Rear brakes Disc, 272x10 mm
Rear suspension Helical spring, Elastic beam
Steering type Steering rack and pinion
Tires size 225/45 R17; 225/40 R18
Wheel rims size 7.5J x 17; 7.5J x 18

Space Seat Leon 5 Sportstourer 2020

Space
Fuel tank capacity 40 l
Kerb Weight 1583 kg
Max load 497 kg
Max. roof load 75 kg
Max. weight 2080 kg
Permitted towbar download 80 kg
