Brand : Mercedes-Benz
Model : S-class
Generation : S-class W223
Body Type : Sedan
Fuel Type : Petrol · Electricity
Engine Type : Hybrid
Battery Capacity : 28.6 KW
Electric Range : 91-109 km
Start Year : 2021
Mercedes-Benz S-class W223 2021 S 580 e (510 Hp) 4MATIC 9G-TRONIC
Photos for cars
Technical Sheet Mercedes-Benz S-class W223 2021
Acceleration 0 - 100 Km/h
: 4.9 sec
Acceleration 0 - 62 Mph
: 4.9 sec
All-electric Range (WLTP)
: 91-109 km
Average Energy Consumption (WLTP)
: 21.9-25.5 kWh/100 km
Battery Capacity
: 28.6 kWh
Body Type
: Sedan
Doors
: 4
Drive Wheel
: All wheel drive (4x4)
Engine Aspiration
: Turbocharger, Intercooler
Engine Systems
: Start & Stop SystemParticulate filter
Fuel System
: Direct injection
Fuel Type
: petrol / electricity
Fuel Tank Capacity
: 67 l
Generation
: S-class (W223)
Kerb Weight
: 2345 kg
Max Speed (electric)
: 140 km/h
Maximum Speed
: 250 km/h, Electronically limited
Modification (Engine)
: S 580 e (510 Hp) 4MATIC 9G-TRONIC
Number Of Gears (automatic Transmission)
: 9 G-TRONIC
Number Of Cylinders
: 6
Power
: 367 Hp @ 5500-6100 rpm.
Power Steering
: Electric Steering
Powertrain Architecture
: PHEV (Plug-in Hybrid Electric Vehicle)
Seats
: 5
Start Of Production
: November, 2021
System Power
: 510 Hp
General Mercedes-Benz S-class W223 2021
| General | |
| Body type | Sedan |
| Brand | Mercedes-Benz |
| Doors | 4 |
| Generation | S-class (W223) |
| Model | S-class |
| Modification (Engine) | S 580 e (510 Hp) 4MATIC 9G-TRONIC |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Seats | 5 |
| Start of production | November, 2021 |
Performance Mercedes-Benz S-class W223 2021
| Performance | |
| Acceleration 0 - 100 km/h | 4.9 sec |
| Acceleration 0 - 60 mph | 4.7 sec |
| Acceleration 0 - 62 mph | 4.9 sec |
| CO2 emissions (WLTP) | 16-23 g/km |
| Combined fuel consumption (WLTP) | 0.7-1 l/100 km |
| Emission standard | Euro 6D-ISC-FCM |
| Fuel Type | petrol / electricity |
| Maximum speed | 250 km/h, Electronically limited |
Electric Mercedes-Benz S-class W223 2021
| Electric | |
| Battery capacity | 28.6 kWh |
| All-electric range (WLTP) | 91-109 km |
| Average Energy consumption (WLTP) | 21.9-25.5 kWh/100 km |
| Max speed (electric) | 140 km/h |
| Electric motor power number 1 | 150 Hp |
| Electric motor Torque number 1 | 440 Nm |
| Engine location number 1 | Electric motor, integrated into transmission |
| System power | 510 Hp |
| System torque | 750 Nm |
Internal Engine Mercedes-Benz S-class W223 2021
| Internal Engine | |
| Compression ratio | 10.5 |
| Cylinder Bore | 83 mm |
| Engine Model/Code | M 256.930 |
| Engine aspiration | Turbocharger, Intercooler |
| Engine displacement | 2999 cm |
| Engine location | Front, Longitudinal |
| Engine systems | Start & Stop SystemParticulate filter |
| Fuel System | Direct injection |
| Number of cylinders | 6 |
| Number of valves per cylinder | 4 |
| Piston Stroke | 92.4 mm |
| Position of cylinders | Inline |
| Power | 367 Hp @ 5500-6100 rpm. |
| Power per litre | 122.4 Hp/l |
| Torque | 500 Nm @ 1600-4500 rpm. |
| Valvetrain | DOHC |
Dimensions Mercedes-Benz S-class W223 2021
| Dimensions | |
| Approach angle | 14.7° |
| Departure angle | 15.9° |
| Front overhang | 877 mm |
| Front track | 1655 mm |
| Height | 1503 mm |
| Length | 5179 mm |
| Minimum turning circle (turning diameter) | 10.7 m |
| Ramp angle | 10.8° |
| Rear (Back) track | 1651 mm |
| Rear overhang | 1196 mm |
| Ride height (ground clearance) | 130 mm |
| Wheelbase | 3106 mm |
| Width | 1954 mm |
Drivetrain Mercedes-Benz S-class W223 2021
| Drivetrain | |
| Drive wheel | All wheel drive (4x4) |
| Front brakes | Ventilated discs |
| Front suspension | Pneumatic suspension |
| Number of Gears (automatic transmission) | 9 G-TRONIC |
| Power steering | Electric Steering |
| Rear brakes | Ventilated discs |
| Rear suspension | Pneumatic suspension |
| Steering type | Steering rack and pinion |
| Tires size | 255/50 R18; 255/45 R19 |
| Wheel rims size | 8J x 18; 8.5J x 19 |
Space Mercedes-Benz S-class W223 2021
| Space | |
| Fuel tank capacity | 67 l |
| Kerb Weight | 2345 kg |
| Max load | 725 kg |
| Max. roof load | 100 kg |
| Max. weight | 3070 kg |
