GMC Sierra HD Crew Cab Standard Box 2015 6.6 Duramax TD V8 (397 Hp) Automatic

GMC Sierra HD Crew Cab Standard Box 2015 6.6 Duramax TD V8 (397 Hp) Automatic
Brand : GMC
Model : Sierra HD
Body Type : Pick-up
Fuel Type : Diesel
Seats : 5
Doors : 4
Start Year : 2015

Technical Sheet

Body Type
: Pick-up
Doors
: 4
Drive Wheel
: Rear wheel drive
End Of Production
: 2017
Engine Aspiration
: Turbocharger, Intercooler
Engine Oil Capacity
: 9.5 l
Engine Systems
: Particulate filter
Fuel Type
: Diesel
Fuel Tank Capacity
: 136 l
Generation
: Sierra 2500HD IV (GMTK2XX) Crew Cab Standard Box
Kerb Weight
: 3222 kg
Modification (Engine)
: 6.6 Duramax TD V8 (397 Hp) Automatic
Number Of Cylinders
: 8
Power
: 397 Hp @ 3000 rpm.
Powertrain Architecture
: Internal Combustion engine
Seats
: 5
Start Of Production
: 2015
General
Body type Pick-up
Brand GMC
Doors 4
End of production 2017
Generation Sierra 2500HD IV (GMTK2XX) Crew Cab Standard Box
Model Sierra 2500HD
Modification (Engine) 6.6 Duramax TD V8 (397 Hp) Automatic
Powertrain Architecture Internal Combustion engine
Seats 5
Start of production 2015
Performance
Fuel Type Diesel
Dimensions
Front track 1748 mm
Height 1988 mm
Length 6083 mm
Minimum turning circle (turning diameter) 15.7 m
Rear (Back) track 1709 mm
Ride height (ground clearance) 213 mm
Wheelbase 3904 mm
Engine
Compression ratio 16
Coolant 22.4 l
Cylinder Bore 103 mm
Engine Model/Code Duramax LML
Engine aspiration Turbocharger, Intercooler
Engine configuration V-engine
Engine displacement 6599 cm
Engine layout Front, Longitudinal
Engine oil capacity 9.5 l
Engine systems Particulate filter
Fuel injection system Diesel Commonrail
Number of cylinders 8
Number of valves per cylinder 4
Power 397 Hp @ 3000 rpm.
Torque 1037 Nm @ 1600 rpm.
Drivetrain
Drive wheel Rear wheel drive
Front brakes Ventilated discs, 350x40 mm
Front suspension Coil spring, Double wishbone, Transverse stabilizer
Number of gears and type of gearbox 6 gears, automatic transmission Allison
Rear brakes Ventilated discs, 360x34 mm
Rear suspension Rigid axle suspension, Leaf spring
Steering type Cone worm with recirculation balls
Tires size 245/75 R17; 265/70 R17; 265/70 R18; 265/60 R20
Wheel rims size 7.5J x 17; 8J x 18; 8.5J x 20
Space
Fuel tank capacity 136 l
Kerb Weight 3222 kg
Max load 1314 kg
Max. weight 4536 kg
