BMW 5 Series Sedan F10 151 2013 520i (170 Hp) Steptronic

BMW 5 Series Sedan F10 151 2013 520i (170 Hp) Steptronic
Brand : BMW
Model : 5 Series
Body Type : Sedan
Fuel Type : Petrol (Gasoline)
Seats : 5
Doors : 4
Start Year : 2013

Technical Sheet BMW 5 Series Sedan F10 LCI 2013

Acceleration 0 - 100 Km/h
: 8.7 sec
Acceleration 0 - 62 Mph
: 8.7 sec
Body Type
: Sedan
Doors
: 4
Drive Wheel
: Rear wheel drive
End Of Production
: 2016
Engine Aspiration
: Twin-power turbo, Intercooler
Engine Oil Capacity
: 5 l
Engine Systems
: Start & Stop System
Fuel Type
: Petrol (Gasoline)
Fuel Consumption (economy) - Combined
: 6.7 l/100 km
Fuel Consumption (economy) - Extra Urban
: 5.5 l/100 km
Fuel Tank Capacity
: 70 l
Generation
: 5 Series Sedan (F10 LCI, 2013)
Kerb Weight
: 1615 kg
Maximum Speed
: 226 km/h
Modification (Engine)
: 520i (170 Hp) Steptronic
Number Of Cylinders
: 4
Power
: 170 Hp @ 5000-6000 rpm.
Power Steering
: Electric Steering
Powertrain Architecture
: Internal Combustion engine
Seats
: 5
Start Of Production
: 2013
Wheel Rims Size
: Front wheel rims: 8J x 17; 8J x 18Rear wheel rims: 8J x 17; 8J x 18; 9J x 18

General BMW 5 Series Sedan F10 LCI 2013

General
Body type Sedan
Brand BMW
Doors 4
End of production 2016
Generation 5 Series Sedan (F10 LCI, 2013)
Model 5 Series
Modification (Engine) 520i (170 Hp) Steptronic
Powertrain Architecture Internal Combustion engine
Seats 5
Start of production 2013

Performance BMW 5 Series Sedan F10 LCI 2013

Performance
Acceleration 0 - 100 km/h 8.7 sec
Acceleration 0 - 60 mph 8.3 sec
Acceleration 0 - 62 mph 8.7 sec
CO2 emissions 156 g/km
Fuel Type Petrol (Gasoline)
Fuel consumption (economy) - combined 6.7 l/100 km
Fuel consumption (economy) - extra urban 5.5 l/100 km
Fuel consumption (economy) - urban 8.7 l/100 km
Maximum speed 226 km/h

Dimensions BMW 5 Series Sedan F10 LCI 2013

Dimensions
Front overhang 832 mm
Front track 1600 mm
Height 1462 mm
Length 4907 mm
Minimum turning circle (turning diameter) 12 m
Rear (Back) track 1627 mm
Rear overhang 1107 mm
Wheelbase 2968 mm
Width 1860 mm

Engine BMW 5 Series Sedan F10 LCI 2013

Engine
Compression ratio 9
Coolant 9.1 l
Cylinder Bore 84 mm
Engine Model/Code N20B16
Engine aspiration Twin-power turbo, Intercooler
Engine configuration Inline
Engine displacement 1592 cm
Engine layout Front, Longitudinal
Engine oil capacity 5 l
Engine systems Start & Stop System
Fuel injection system Direct injection
Number of cylinders 4
Number of valves per cylinder 4
Power 170 Hp @ 5000-6000 rpm.
Torque 250 Nm @ 1500-4700 rpm.

Drivetrain BMW 5 Series Sedan F10 LCI 2013

Drivetrain
Drive wheel Rear wheel drive
Front brakes Ventilated discs
Front suspension Double wishbone, Transverse stabilizer
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Power steering Electric Steering
Rear brakes Ventilated discs
Rear suspension Independent multi-link spring suspension with stabilizer
Steering type Steering rack and pinion
Tires size Front wheel tires: 225/55 R17; 245/45 R18Rear wheel tires: 225/55 R17; 245/45 R18; 275/40 R18
Wheel rims size Front wheel rims: 8J x 17; 8J x 18Rear wheel rims: 8J x 17; 8J x 18; 9J x 18

Space BMW 5 Series Sedan F10 LCI 2013

Space
Fuel tank capacity 70 l
Kerb Weight 1615 kg
Max load 610 kg
Max. weight 2225 kg
