Mercedes-Benz S-class W223 2021
S 580 e (510 Hp) 4MATIC 9G-TRONIC
Hybrid Car
Body Type Sedan
Battery Capacity 28.6 KW
91-109 km
Electric Range
250 km/h
Maximum Speed
4
Doors
Mercedes-Benz S-class W223 2021 Key Specs
Acceleration 0 - 100 Km/h
4.9 sec
Acceleration 0 - 62 Mph
4.9 sec
All-electric Range (WLTP)
91-109 km
Average Energy Consumption (WLTP)
21.9-25.5 kWh/100 km
Battery Capacity
28.6 kWh
Body Type
Sedan
Doors
4
Drive Wheel
All wheel drive (4x4)
Engine Aspiration
Turbocharger, Intercooler
Engine Systems
Start & Stop SystemParticulate filter
Fuel System
Direct injection
Fuel Type
petrol / electricity
Fuel Tank Capacity
67 l
Generation
S-class (W223)
Kerb Weight
2345 kg
Max Speed (electric)
140 km/h
Maximum Speed
250 km/h, Electronically limited
Modification (Engine)
S 580 e (510 Hp) 4MATIC 9G-TRONIC
Number Of Gears (automatic Transmission)
9 G-TRONIC
Number Of Cylinders
6
Power
367 Hp @ 5500-6100 rpm.
Power Steering
Electric Steering
Powertrain Architecture
PHEV (Plug-in Hybrid Electric Vehicle)
Seats
5
Start Of Production
November, 2021
System Power
510 Hp
Mercedes-Benz S-class W223 2021 Gallery
Mercedes-Benz S-class W223 2021 Technical Specifications
General
Body type
Sedan
Brand
Mercedes-Benz
Doors
4
Generation
S-class (W223)
Model
S-class
Modification (Engine)
S 580 e (510 Hp) 4MATIC 9G-TRONIC
Powertrain Architecture
PHEV (Plug-in Hybrid Electric Vehicle)
Seats
5
Start of production
November, 2021
Performance
Acceleration 0 - 100 km/h
4.9 sec
Acceleration 0 - 60 mph
4.7 sec
Acceleration 0 - 62 mph
4.9 sec
CO2 emissions (WLTP)
16-23 g/km
Combined fuel consumption (WLTP)
0.7-1 l/100 km
Emission standard
Euro 6D-ISC-FCM
Fuel Type
petrol / electricity
Maximum speed
250 km/h, Electronically limited
Electric
All-electric range (WLTP)
91-109 km
Average Energy consumption (WLTP)
21.9-25.5 kWh/100 km
Battery capacity
28.6 kWh
Electric motor Torque number 1
440 Nm
Electric motor power number 1
150 Hp
Engine location number 1
Electric motor, integrated into transmission
Max speed (electric)
140 km/h
System power
510 Hp
System torque
750 Nm
Internal Engine
Compression ratio
10.5
Cylinder Bore
83 mm
Engine Model/Code
M 256.930
Engine aspiration
Turbocharger, Intercooler
Engine displacement
2999 cm
Engine location
Front, Longitudinal
Engine systems
Start & Stop SystemParticulate filter
Fuel System
Direct injection
Number of cylinders
6
Number of valves per cylinder
4
Piston Stroke
92.4 mm
Position of cylinders
Inline
Power
367 Hp @ 5500-6100 rpm.
Power per litre
122.4 Hp/l
Torque
500 Nm @ 1600-4500 rpm.
Valvetrain
DOHC
Dimensions
Approach angle
14.7°
Departure angle
15.9°
Front overhang
877 mm
Front track
1655 mm
Height
1503 mm
Length
5179 mm
Minimum turning circle (turning diameter)
10.7 m
Ramp angle
10.8°
Rear (Back) track
1651 mm
Rear overhang
1196 mm
Ride height (ground clearance)
130 mm
Wheelbase
3106 mm
Width
1954 mm
Drivetrain
Drive wheel
All wheel drive (4x4)
Front brakes
Ventilated discs
Front suspension
Pneumatic suspension
Number of Gears (automatic transmission)
9 G-TRONIC
Power steering
Electric Steering
Rear brakes
Ventilated discs
Rear suspension
Pneumatic suspension
Steering type
Steering rack and pinion
Tires size
255/50 R18; 255/45 R19
Wheel rims size
8J x 18; 8.5J x 19
Space
Fuel tank capacity
67 l
Kerb Weight
2345 kg
Max load
725 kg
Max. roof load
100 kg
Max. weight
3070 kg
