Lynk and Co 09 2024 EM-P 2.0TD T5 (555 Hp) Plug-in Hybrid E-AWD DHT Pro

Lynk and Co 09 2024 EM-P 2.0TD T5 (555 Hp) Plug-in Hybrid E-AWD DHT Pro
Brand : Lynk and Co
Model : 09
Generation : 09
Body Type : SUV
Engine Type : Hybrid
Battery Capacity : 40.1 KW
Doors : 5
Start Year : 2024

Technical Sheet

Acceleration 0 - 100 Km/h
: 4.9 sec
Acceleration 0 - 62 Mph
: 4.9 sec
Body Type
: SUV
Doors
: 5
Drive Wheel
: All wheel drive (4x4)
Engine Aspiration
: Turbocharger, Intercooler
Engine Oil Capacity
: 5.6 l
Fuel Type
: Petrol / electricity
Fuel Tank Capacity
: 70 l
Generation
: 09
Gross Battery Capacity
: 40.1 kWh
Kerb Weight
: 2470 kg
Maximum Speed
: 239 km/h
Modification (Engine)
: EM-P 2.0TD T5 (555 Hp) Plug-in Hybrid E-AWD DHT Pro
Number Of Cylinders
: 4
Power
: 254 Hp @ 5500 rpm.
Power Steering
: Electric Steering
Powertrain Architecture
: PHEV (Plug-in Hybrid Electric Vehicle)
Seats
: 6-7
Start Of Production
: January, 2024
System Power
: 555 Hp
System Torque
: 844 Nm
Wheel Rims Size
: 20

General

General
Body type SUV
Brand Lynk & Co
Doors 5
Generation 09
Model 09
Modification (Engine) EM-P 2.0TD T5 (555 Hp) Plug-in Hybrid E-AWD DHT Pro
Powertrain Architecture PHEV (Plug-in Hybrid Electric Vehicle)
Seats 6-7
Start of production January, 2024

Performance

Performance
Acceleration 0 - 100 km/h 4.9 sec
Acceleration 0 - 60 mph 4.7 sec
Acceleration 0 - 62 mph 4.9 sec
Emission standard China VI
Fuel Type Petrol / electricity
Fuel consumption (economy) - combined (WLTC) 1 l/100 km
Maximum speed 239 km/h

Electric

Electric
Gross battery capacity 40.1 kWh
Battery location Below the floor
All-electric range (WLTC) 160 km
Average Energy consumption (WLTC) 21.8 kWh/100 km
Charging ports number 0 Log in to see.
Electric motor power number 1 136 Hp
Electric motor Torque number 1 320 Nm
Electric motor location number 1 Integrated into the transmission
Electric motor type number 1 Synchronous
Electric motor power number 2 212 Hp
Electric motor Torque number 2 309 Nm
Electric motor location number 2 Rear axle, Transverse
Electric motor type number 2 Synchronous
System power 555 Hp
System torque 844 Nm

Internal Engine

Internal Engine
Compression ratio 10.8
Cylinder Bore 82 mm
Engine Model/Code JLH-4G20TDC
Engine aspiration Turbocharger, Intercooler
Engine configuration Inline
Engine displacement 1969 cm
Engine layout Front, Transverse
Engine oil capacity 5.6 l
Engine oil specification Log in to see.
Fuel injection system Direct injection
Number of cylinders 4
Number of valves per cylinder 4
Piston Stroke 93.2 mm
Power 254 Hp @ 5500 rpm.
Power per litre 129 Hp/l
Torque 350 Nm @ 1800-4800 rpm.
Valvetrain DOHC

Dimensions

Dimensions
Approach angle 21°
Departure angle 20°
Front track 1680 mm
Height 1780 mm
Length 5042 mm
Minimum turning circle (turning diameter) 12.3 m
Rear (Back) track 1684 mm
Ride height (ground clearance) 190 mm
Wheelbase 2984 mm
Width 1977 mm

Drivetrain

Drivetrain
Drive wheel All wheel drive (4x4)
Front brakes Ventilated discs
Front suspension Double wishbone, Air Suspension - Optional
Number of gears and type of gearbox 3 gears, automatic transmission DHT Pro
Power steering Electric Steering
Rear brakes Ventilated discs
Rear suspension Independent multi-link suspension, Leaf spring, Air Suspension - Optional
Steering type Steering rack and pinion
Tires size 275/40 R20
Wheel rims size 20

Space

Space
Fuel tank capacity 70 l
Kerb Weight 2470 kg
Max load 550 kg
Max. weight 3020 kg
